顯示種產(chǎn)品
| Model |
Channel
|
VRWM (V) max
|
Vbr (V) min
|
Vc (V) max
|
Contact discharge (kV) max
|
Air discharge (kV) max
|
Ipp (A) min (8/20uS)
|
Capacitance (pF) typ
|
Package
|
AEC-Q101
|
|---|---|---|---|---|---|---|---|---|---|---|
|
CSL05FU |
1 | 5 | 6 | 18 | +/-8 | +/-15 | 4 | 0.6 | DFN1006 | no |
|
CSL05D2U |
4 | 5 | 6 | 15 | +/-12 | +/-17 | 4 | 0.8 | SOT23-6L | no |
|
CSL05U6U |
6 | 5 | 6 | 14 | +/-20 | +/-25 | 4 | 0.8 | DFN3514P14 | no |
|
CSL05G4U |
4 | 5 | 6 | 21.5 | +/-20 | +/-25 | 4 | 0.45 | DFN2510P10 | no |
|
CSL05F2U3 |
1 | 5 | 6 | 25 | +/-10 | +/-15 | 4 | 0.6 | DNF1006 | no |
|
CSL05FB |
1 | 5 | 6 | 18 | +/-10 | +/-15 | 4 | 0.35 | DFN1006-2L | no |
